PC 2500

PC 2500

CHILLERS

2.5 kW / 8530 Btu/h / 0.7 TONS

Our PC 2500 (NEMA Type 12) compact, powerful and efficient chillers offer reliable and versatile liquid cooling. Multiple configurations ensure the PC 2500 meets the requirements of broad range of applications. The efficient design with low GWP refrigerant delivers an environmentally friendly operation. Design: powder coated RAL 7021(black grey)


Compact & Ready to Use

Fully assembled air-cooled chiller designed for quick installation and seamless integration into your setup

Powerful Cooling Performance

Delivers a reliable 2.5 kW cooling capacity, ensuring stable temperatures even under demanding conditions.

Energy Efficient

Equipped with a modern micro-channel condenser and low refrigerant volume with low GWP R513A for environmentally friendly, cost-effective operation.

Quiet & Reliable Operation

Engineered with a low-noise pump and robust components, making it ideal for both industrial and indoor environments.

Simplified Maintenance

Features a tool-free quick-release filter system, reducing downtime and keeping performance at its best.

Built for Versatility

Designed to perform in ambient temperatures up to +122 °F, making it a perfect fit for a wide range of applications.

Hydraulic Protection(H) Configuration

Ensures pump and system safety with built-in flow monitoring, dry-run protection, and hydraulic bypass to prevent pressure overloads.

Hydraulic + Smart Cooling(HS) Configuration

Adds intelligent temperature control, early fault detection, and service-friendly diagnostics for improved performance and uptime.

Hydraulic + Smart + Precision Cooling (HSP)

Delivers maximum stability with ±1 K temperature accuracy, hot gas bypass control, and optimized fan regulation for sensitive applications.

MODEL NUMBERPC 2500
PART NUMBER421602530034216025300442160253005
ConfigurationHHSHSP
RATED VOLTAGE AC 50 /60230 1~50/60
COOLING CAPACITY BTU/hr8,530
kW2.5
Tons0.7
FLOW RATE of PUMPGPM2
LPM7.5
PUMP PRESSUREpsi43
bar3
TANK VOLUME (gal/l)2.6/10
Connections (medium) IG (BSP)3/8"
Dry Weight (lb/kg)144/65
Ambient Temp. RangeMin (°C/°F)10/45
Max (°C/°F)50/122
MediumWater/Glycol80%/20%
Medium Temp. (Outlet)+55°F .. +86°F (+13°C … +30°F) Factory Set Point 64°F (18°C)
Target Value Tolerance±2 K±1 K
MAX POWER CONSUMPTION (kW)1.6
MAX CURRENT CONSUMPTION (A)7.5
AIR VOLUME FLOW (m^3/h)1,290
REFRIGERANTR1513A
MAX NOISE LEVEL @ 60 Hz (EN ISO 3741)65dB
WIDTH in27.9
DEPTH in 25.8
HEIGHT in (with damper feet)18.6
PC 2500
MANUAL
DATA SHEET
DRAWINGS
MODEL

Cooling Capacity

SKU: 42130245011-1 Category:

Subject to technical amendments and misprints.
